Full Size (II)

Siemens Arcadis Varic

Compact, ergonomic and flexibile. This C-Arm is most selected for use in pain, spine and orthopedic applications.


II Size: 9"
Max Power: 2.3 kW

More Info
Philips BV Pulsera

Robust and customizable, valued for its power and economic cost. Widely used for multipurpose applications that require extended, powerful penetration.

II Size: 9" or 12"
Max Power: 7.5 or 15 kW

More Info
Siemens Arcadis Avantic

Most powerful and largest II based system on the market. Used for all applications, but is most valued for Vascular.


II Size: 13"
Max Power: 25 kW

More Info

Full Size (FD)

Philips Veradius

Digital Flat Detector for exceptional image quality at lower dose. Perfect for any clinical application.

FD Size: 10.3"
Max Power: 15 kW

More Info
Philips Veradius Neo

Improved C design that is especially helpful for accommodating bariatric patients and larger areas of anatomy.

FD Size: 10.3"
Max Power: 15 kW

More Info
Philips Veradius Unity

All new touchscreen tablet user interface for exceptional ease of use during image acquisition and postprocessing.

FD Size: 10.3"
Max Power: 15 kW

More Info

Cart

Cart Empty

As a surgeon, you need high-quality information to help you perform an increasing number of challenging interventions. The Philips Veradius Neo C-Arm is counterbalanced with a thin 10.3” flat detector that delivers consistent edge-to-edge image quality and superb contrast resolution to support critical decision making. One of the advantages of this C-Arm unit is its design, which provides more room to see the patient during mobile fluoroscopy procedures. The optimized C-arc is larger and allows for easy patient access, especially for bariatric patients. In addition, the powerful 15 kW generator and high heat capacity of the Veradius Neo delivers enough power to image large patients with outstanding images. With its optimized C-arc geometry, Flat Detector imaging technology and advanced radiation dose settings, the Philips Veradius Neo helps you take the next step in excellence as you carry out complex vascular, cardiac, and orthopedic procedures procedures.

Specifications Datasheet

X-ray Generation
Tube
Rotating anode with active heat management
Nominal Power
15kW: 120kV, 125mA
Imaging
Flat Detector
10.3"
FD Resolution
1560x1420 pixels
User Interface
Workstation Monitors
Two 19" LCD Flat Panel
Touchscreen
(Primary monitor only)
C-Arm Monitor
12" Reference LCD
Geometry
Free space within C-arm
30.3"
Angulation
+90° to -50°
C-arm depth
29"
Source Image Distance
39.1"
Rotation
± 200°
Lowest lateral working position
40.4"
Connectivity
Video Output
BNC, DVI(Optional), HDMI(Optional)
Networking (DICOM Optional)
Wired
Other
USB(Image Export), S-Video Input
Dimensions
C-Arm
66.4-85.7" H x 29" W x 77-108.6" L
C-Arm Weight
757 lbs
Workstation
69" H x 32" W x 37" D
Workstation Weight
430 lbs
Request a Quote
Term
Save up to 25% on 5 Years!
Ortho/Pain Package
Vascular Package
Cardiac Package
Paper Printer
DVD Recorder
Ext Video Output
DICOM Package
Philips Veradius Neo
